Fiber


In recent years optical fibers have become widely used as a communications infrastructure for access networks, also known as Fiber-to-the-x (FTTx), where "x" represents Home (FTTH), Building/Business (FTTB) or Curb/Cabinet (FTTC). According to market research, fiber is the largest growing technology for fixed broadband connections, significantly exceeding the growth of all other technologies, including copper, cable and wireless technologies.

Optical fibers are enjoying rising popularity thanks to their inherent advantages over the traditional copper twisted pairs, including significantly higher bandwidth capacity, lower power loss, greater reliability and immunity to interference.

Different fiber deployment technologies are used in the access network. Passive Optical Network (PON) is the prevalent one, mainly thanks to its cost-effective architecture and its low energy consumption. PON uses a tree topology, in which the fiber is split once or several times between the service provider's central office or other point of presence and the subscribers' premises.

Gigabit PON (GPON) is currently the most common and fastest growing PON technology. It was in initially standardized by the ITU in 2004 but went through some major modifications since then. Its throughput is 2.5 Gbit/s downstream and 1.25 Gbit/s upstream and it is capable of supporting up to 128 subscriber end points, commonly called ONUs or ONTs, over a single PON, with distances of up to 20 km.

As new services are being rolled out over PON deployments, the need for higher bandwidth continues to grow. New PON technologies are being developed to address this need. The XGS-PON technology provides up to 10 Gbit/s in both the downstream and the upstream, while XG-PON provides 10 Gbit/s downstream and 2.5 Gbit/s upstream. Both can support up to 256 ONUs/ONTs.

NG-PON2 expands the bandwidth over the PON to 40 Gbit/s in both directions, and this is achieved by stacking four XGS-PON systems using different wavelengths on a single PON, so that their aggregate data rate is 40 Gbit/s symmetrical. This technology is also referred to as Time and Wavelength Division Multiplexing (TWDM).

1G-EPON and 10G-EPON are PON technologies which were standardized by the IEEE in parallel with GPON and XGS-PON, respectively. 1G-EPON provides 1 Gbit/s in both directions, while 10G-EPON provides up to 10 Gbit/s in both directions.

The 25GS-PON technology is based on XGS-PON and provides up to 25 Gbit/s in both the downstream and the upstream. It has not been standardized by the official standards organizations but is supported by a number of vendors.

The 50G-PON technology has been standardized by the ITU as the next technology after XGS-PON. It provides up to 50 Gbit/s in both the downstream and the upstream and also supports some asymmetric options, in which the upstream has lower line rates.

XGS-PON products have been available in the market for a number of years, and many service providers are already deploying them. XG-PON already has limited commercial deployments, which are focused mainly in a number of countries in Asia.

10G-EPON products are also available in the market and have commercial deployments in a number of countries in Asia, as well as in North America, where many of the MSOs have adopted these technologies.

25GS-PON products are already available in the market, and some service providers are in advanced phases of testing them and launching pilot deployments.

NG-PON2 products have been available in the market for a number of years, but this technology has only been adopted by a limited number of service providers.

50G-PON is still in its early phases with first products being launched. While some service providers are focusing on 25GS-PON as an immediate solution for expanding the bandwidth of their PON and others have adopted NG-PON2 for this purpose, there are also many others who are planning to begin testing of 50G-PON in the near future for the purpose of deploying it in the coming years.
